Overview

Secure, stylish and futuristic, the K9 Push Pull Smart Lock is literally what convenience at your fingertips looks and feels like. With a durable universal opening handle that includes a biometric fingerprint scanner, and the capacity to hold 100 different fingerprints, this keyless entry system is perfect for homes and offices that seek quick, easy and secure entry solutions.

Features:
User-friendly access
Sensitive Touch pad screen
Just one step to open
Automatic locking
Auto polling
Easy installation
Sweden FPC Fingerprint Sensor
Fake PIN code feature
Double authentication
Defense mode
In home security (double-locking)
Safe handle
Power bank back-up
Low battery warning signal
Interface with IOT module
Master function

TECHNICAL SPECIFICATIONS
Material: Zinc Alloy
Operating Conditions: Temperature Range: -20 to 55 Celsius
Humidity: 15% to 90%

Lock Dimensions
Height: 400mm
Width: 80mm
Thickness: 65mm

Door Thickness
38-60 mm (default)
60-90 mm (optional)

Mortise Dimensions Single
Height: 240mm
Width: 25mm
Depth: 89mm
Triple Height: 240mm
Width: 25mm
Depth: 93mm
Recognition Time: <0.5s

Unlocking Options
Fingerprint / Bluetooth / Pin Code / Swipe Card / Key

False Acceptance Rate (FAR) : <0.0001%

Fingerprint Capacity 100
False Recognition Rate (FRR): 0.01%

RF Card Capacity: 100

Power Supply
8 x AA alkaline batteries

Pin Code 6-12 digits
1 Master code
10 user pin codes

Battery Life: Up to 1 year
LCD Display No
Back Up Power Source: 5v power bank

RF Card Frequency: Mifarel 13.56 MHz

Wrong Code Entry: 10 attempts will deactivate the keypad for 5 minutes

Keypad Material: IML

Passage Mode: Yes (Auto/Manual Locking)

Sliding Enclosure: No

Auto Lock Options: Off for 1.5 seconds

IP Rating: IP45

Opening Direction: Universal

Voice Guided: Yes - English & Chinese

Backset: 60mm

Suitable Applications: Home / Office

Centre Distance: 72mm

Suitable Fitting Materials: Wood / Steel Doors

Optional: Bluetooth / Z-Wave / Remote Control
Cross Weight 5.5kg
